1. Product characteristics
Safety and sealing: Adopt unique production technology and special structure design to ensure the safety and sealing of the battery.
Maintenance-free: The unique gas re-integration system can regenerate the generated gas into water, adsorptive fiberglass separator, without compensating electro-hydraulic during the life cycle.
Low self-discharge: the use of corrosion-resistant special lead-calcium alloy made of grids, self-discharge control at the minimum, room temperature storage at 25 degrees Celsius, can be within six months without supplementary electricity.
The temperature range is wide: the battery can be used at the temperature range of -10 - 40 C.
Easy installation: it can be installed vertically and horizontally according to the requirements of users.
Long life design: Heavy lead-calcium alloy plate with corrosion-resistant structure ensures the floating charge life of the battery.
2. application scope
Suitable for communication, telecommunications, power, IT networks, ships and other UPS, EPS power supply system, solar photovoltaic wind energy storage system.
3. technical parameters
規(guī)格型號 | 標(biāo)稱電壓(V) | 20HR/10HR額定容量(Ah) | 外型尺寸(mm) | |||
長(mm) | 寬(mm) | 高(mm) | ||||
6-GFM-24 | 12 | 24 | 165 | 125 | 180 | |
6-GFM-38 | 12 | 38 | 197 | 165 | 180 | |
6-GFM-65 | 12 | 65 | 350 | 165 | 175 | |
6-GFM-90 | 12 | 90 | 328 | 173 | 242 | |
6-GFM-100 | 12 | 100 | 408 | 172 | 236 | |
6-GFM-120 | 12 | 120 | 408 | 172 | 236 | |
6-GFM-150 | 12 | 150 | 483 | 170 | 243 | |
6-GFM-200 | 12 | 200 | 522 | 238 | 220 | |
GFM-200 | 2 | 200 | 108 | 176 | 367 | |
GFM-500 | 2 | 500 | 244 | 176 | 367 | |
GFM-600 | 2 | 600 | 301 | 176 | 367 | |
GFM-800 | 2 | 800 | 409 | 176 | 367 | |
GFM-1000 | 2 | 1000 | 477 | 176 | 367 |
